Fiber Optic Face Plate Box

  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
  • CT-F315 12 Core Fiber Optic Splicing Plastic Bo
CT-F315 12 Core Fiber Optic Splicing Plastic Bo CT-F315 12 Core Fiber Optic Splicing Plastic Bo CT-F315 12 Core Fiber Optic Splicing Plastic Bo CT-F315 12 Core Fiber Optic Splicing Plastic Bo CT-F315 12 Core Fiber Optic Splicing Plastic Bo CT-F315 12 Core Fiber Optic Splicing Plastic Bo

CT-F315 12 Core Fiber Optic Splicing Plastic Bo

Description

The equipment is used as a termination point for the feeder cable to connect with drop cable inFTTX communication network system. The fiber splicing. splitting, distribution can be done in this box and meanwhile it provides solid protection and management for the FTTX network building



Features

1、Total enclosed structure.

2、 Material: PC+ABS, wet-proof、 water-proof、dust proof、antiaging, protection level up to IP65.

3、 Clamping for feeder cable and drop cable, fiber splicing, fixation,  storage distribution ... etc all in one.

4 、 Cable, pigtails, patch cord:s are running through own path  without disturbing each other, cassette type SC adaptor .installation,  easy maintenance.

5、 Distribution panel can be flipped up, feeder cable can be placed  in a cup-joint way, easy for maintenance and installation.

6 、 Cabinet can be installed lby the way of wall-mounted or poledmounted,suitable for both indoor and outdoor uses.
